DRS4D-NXT
Antenne Radar Sensor Serie DRS Articolo : IMD03456001RADOME DOPPLER RADAR 25 W
PREZZO : NC
Caratteristiche tecniche
Alimentazione : 12/24 V
Dimensione : 24''
Fascio : 3.9 °
Peso : 7.3 Kg
Potenza : 25 W
Scala : 36 NM
Solid-State : YES
Tipo : Radome
Velocita Rotazione Antenna : 24/36/48 RPM
Videos
Parti e accessori
| 00152404000 | OP03-259-4 EMC MODIFICATION KIT | NC |
| 00142625000 | OP03-239 | NC |
| 00152403000 | OP03-259-3 EMC MODIFICATION KIT | NC |
| 00152402000 | OP03-259-2 EMC MODIFICATION KIT | NC |
| 00152401000 | OP03-259-1 EMC MODIFICATION KIT | NC |
| 00107834000 | OP03-208 RADOME MOUNT | NC |
| 00151260000 | FRU-2P5S-FF-10M-A CABLE 10M ALIM/ETHERNET | NC |
| 00137650000 | CABLE ASSEMBLY FRU-2P5S-FF-30M - Sostituito da 00151268000 | NC |
| 00151268000 | FRU-2P5S-FF-30M-A | 274,50 € IVA inclusa |
| 00137649000 | CABLE ASSEMBLY FRU-2P5S-FF-20M - Sostituito da 00151264000 | NC |
| 00137648000 | FRU-2P5S-FF-15M CABLE ASSEMBLY - Sostituito da 00151262000 | NC |
| 00151262000 | FRU-2P5S-FF-15M-A | NC |
| 00137646000 | FRU-2P5S-FF-10M CABLE EQUIPE 10M - Sostituito da 00151260000 | NC |
| 00151264000 | FRU-2P5S-FF-20M-A CABLE EQUIPE | 207,40 € IVA inclusa |
| 00003671600 | DRS4D-NXT-E RADAR SENSOR | NC |
| 00142611000 | 03-2479(REED SW-2P) REED SWITCH ASSEMBLY | NC |
| 00143463000 | RTR-115 RADIATOR RADIATOR ASSEMBLY WITH BASE | NC |
| 00143464000 | RTR-115 SPU COVER SPU COVER ASSEMBLY | NC |
| 00143456000 | 03P9603(LF) SPU PRINTED CIRCUIT BOARD | NC |
| 00143457000 | 03P9602(LF) TRX TRX BASE ASSEMBLY | NC |
| 00143458000 | DRS4D-NXT DOME-LOWER RADOME LOWER ASSEMBLY | NC |
| 00143459000 | DRS4D-NXT DOME UPPER RADOME UPPER ASSEMBLY | NC |
| 00143462000 | RTR-115 W-GUIDE WAVEGUIDE ASSEMBLY | NC |
| 00103114000 | RM-9794 DC GEARED MOTOR | NC |
