FAR2238SNXTBB
Radars maritimes série FR & FARRADAR BLACK BOX IMO 250 W S-BAND SSD SOLID STATE - SANS MAGNETRON (SANS RADIATEUR NI CABLE)
Caractéristiques techniques
Alimentation : 100-230 V
DVI OUTPUT : 2
Echelle : 96 NM
Puissance : 250 W
Résolution : 1280 x 1024/1600 x 1200/1920 x 1200 Pixels
Solid-State : 1
Taille : 12 ft
Vitesse de Rotation : 24/42 RPM
Vidéos
Pièces et accessoires
| 00150773000 | OP03-257 ANTENNA REINFORCEMENT KIT RSB-128/130 | NC |
| HUB-3000 | HUB3000 (FMD3200B) | NC |
| 00125991000 | S03-92-40(8P) RW-00136 40M W/VH8 CONNECTOR 03S001360 | NC |
| 00125992000 | S03-92-50(8P) RW-00136 50M W/VH8 CONNECTOR 03S001360 | NC |
| 00142121000 | SP03-17641(BOX) SPARE PARTS PSU-014/RPU-025 | NC |
| 00143754000 | XH10P-W-6P L=20M CABLE ASSEMBLY 03S9610-5 | NC |
| 00143755000 | XH10P-W-6P L=30M CABLE ASSEMBLY 03S9610-5 | NC |
| 00148924000 | XH10P-W-5P-A L=1.5M CABLE ASSEMBLY 03S9698-1 - Remplacé par 00159584000 | NC |
| 00148947000 | OP03-245 FLUSH MOUNT KIT RCU-014B | NC |
| 00149656000 | OP03-247-1 LAN SIGNAL CONVERTER (2 units) RSB-133 FAR2238SNXT | NC |
| 00149664000 | OP03-248 HIGH SPEED KIT 42 RPM FAR2238S RPU-025 FAR2238S 2238SNXT | NC |
| 00149690000 | OP03-252 DVI-BNC CABLE KIT RPU-025 | 514,89 € TTC (22%) |
| 00150524000 | PM-52B OP03-254-1 KIT PERFORMANCE MONITOR RSB-133 FAR2238 NXT | NC |
| 00125990000 | S03-92-30(8P) RW-00136 30M W/VH8 CONNECTOR 03S001360 | NC |
| 00152327000 | OP03-258-1 RP BOARD INSTALLATION KIT RPU025-E CARTE MAPMEDIA | NC |
| WV-100 WAVE ANALYZER | L'analyseur de vagues WV-100, connecté au radar de navigation, permet d?analyser les hauteurs de vagues en temps réel. | NC |
| 00159584000 | XH10P-W-5P-A L=1.5M CABLE ASSEMBLY 03S9698-2 | 101,42 € TTC (22%) |
| 00159585000 | XH10P-W-5P-A L=10M CABLE ASSEMBLY (RCU-RCU) 03S9698-2 | 200,14 € TTC (22%) |
| 00159586000 | XH10P-W-5P-A L=20M pour télécomande RCU-016B | NC |
| 00159587000 | XH10P-W-5P-A L=30M CABLE ASSEMBLY (RCU-RCU) 03S9698-2 | 375,81 € TTC (22%) |
| 00820664000 | S03-9-5(8-8P) SIGNAL CABLE ASSY. | NC |
| 00820665000 | S03-9-10(8-8P) SIGNAL CABLE ASSY. | NC |
| 00820916000 | S03-9-15(8-8P) SIGNAL CABLE ASSY. 15M | NC |
| 00853562000 | OP03-182 CLAMP ASSEMBLY RCU-014 | NC |
| 00853563000 | FP03-09870 KIT ENCASTREMENT RCU-014/015/016 | NC |
| 00854246000 | CP03-28901 CONNECTEUR | 60,52 € TTC (22%) |
| 00124770000 | XH10P-W-5P-A L=20M - Remplacé par 00159586000 | 275,20 € TTC (22%) |
| 00008335500 | RJB-001 BOITE DE JONCTION FAR21X7 | NC |
| 00113296010 | DVI-D/D S-LINK Câble DVI 5m pour écran extérieur | NC |
| 00113398010 | DVI-D/D Câble DVI blindé 10m pour écran extérieur | 912,35 € TTC (22%) |
| 00116789010 | MOD-Z072-050+ Câble réseau RJ45 <-> RJ45 4 paires - 5m | 89,06 € TTC (22%) |
| 00120805000 | CP24-02900(10M) INSTALLATION MATERIALS | NC |
| 00120806000 | CP24-02910(20M) INSTALLATION MATERIALS | NC |
| 00120807000 | CP24-02920(30M) INSTALLATION MATERIALS | NC |
| 00125989000 | S03-92-15(8P) RW-00136 15M W/VH8 CONNECTOR 03S001360 | NC |
| HUB-100 | HUB-100 SWITCH RESEAU LAN FAR-28X7 | NC |
| 00124769000 | XH10P-W-5P-A L=10M CABLE ASSEMBLY (RCU-RCU) 03S9698-1 | NC |
| 00124771000 | XH10P-W-5P-A L=30M CABLE ASSEMBLY (RCU-RCU) 03S9698-1 - Remplacé par 00159587000 | NC |
| 00004011000 | AD100 Convertisseur pour gyro compas (Clock & Data + NMEA0183) | NC |
| 00125258000 | DSUB9P-X2-A-L5M CABLE ASSEMBLY 24S104360 | NC |
| 00125259000 | DSUB9P-X2-A-L10M CABLE EQUIPE 24S104360 | 340,29 € TTC (22%) |
| 00125432000 | DE-ICER KIT FAR2218/FAR3210 DE-ICER KIT RSB-128 | NC |
| 00125433000 | DE-ICER KIT FAR2238/FAR3230 DE-ICER KIT RSB-129/133 | NC |
| 00003658700 | RCU-031-E CONTROL UNIT | NC |
| 00003428600 | RCU-016B CONTROL UNIT | NC |
| 00003428400 | RCU-015B-S CONTROL UNIT RADAR CONTROL UNIT | NC |
| 00003329400 | HUB-3000-MIJ INTELLIGENT HUB | NC |
| 00150579000 | SN30CF ANTENNA RADIATOR 10FT ANTENNA RADIATOR ASSEMBLY | NC |
| SN24CF | RADIATEUR SN24CF (FAR3230SB/3230SSDB/FAR2238SB/FAR2238SSDB) pour navire non IMO | NC |
| SN36CF | RADIATEUR SN36CF (FAR3230SB/3230SSDB/FAR2238SB/FAR2238SSDB) | NC |
| 00125983000 | RW-00135-L15M CABLE EQUIPE SIGNAL 15M 03S001352 | NC |
| 00125986000 | CABLE RW-00135-L 30M (FAR31X0) | NC |
| 00125987000 | RW-00135-L40M CABLE EQUIPE SIGNAL 40M 03S001352 | 1 619,44 € TTC (22%) |
| 00125988000 | RW-00135-L50M CABLE EQUIPE SIGNAL 50M 03S001351 | NC |
