Description
Printing on the FAX408
This weather receiver FAX408 collects and produces crucial information on all weather conditions at sea. For the operation of the FAX408, a computer or a connection to the network are not necessary: it is a completely autonomous product.
The features of this FAX408 weather receiver are:
- Clear weather maps and nine-grayscale satellite images on 8 "thermal paper Automatic channel selection by evaluating the quality of the signal reception
- All known fax channels in the 2-25 MHz bands are pre-programmable channels available
- Fully automatic operation thanks to an integrated programmer (16 programs can be set per week for automatic operation)
- Quiet thermal printing thanks to minimal mechanical components
Product advantages
The FAX408 offers the ability to print free weather maps and satellite images. The function "Automatic and optimal search of the best channel" is integrated. The 150 known Facsimile channels in the 2-25 MHz frequency bands are preprogrammed. A supplementary memory of 164 user channels is also available.
Features
The weather receiver FAX408 :
- Frequency from 2 to 25 MHz in steps of 100 Hz
- 12 or 24 VDC power supply
- Consumption from 1.15 to 2.3 A 216 mm x 20 m thermal paper
- Optional FAX-5 active antenna
In the box
1 X Weather receiver FAX408
1 X Ground cable, 2m
1 X Power cable
1 X PL256 socket
1 X Roll of thermal paper
2 X Fuses
1 X Set of screws
1 X Print head cleaning sheet
1 X Simplified User Guide Laminated (Multilingual)
1 X User Manual
Technical characteristics
Brand : FURUNO
Consuption : 27.6 W
Display : paper
Power input : 12/24 V
Type : Facsimile / Navtex
Function : Receiver
Parts and accessories
| 00130873000 | 04S4176 R4 54 597 FAX-5 ANTENNE FOUET 2.60M 04S4176 | NC |
| 00109338010 | CABLE ASSEMBLY 04S4168 *30M* 04S4168 - Replaced by 00159579000 | NC |
| 00109337010 | 04S4168 CAVO ANTENNA 20M NX700 PER NAVTEX/WEATHER FAX 04S4168 - Replaced by 00159578000 | NC |
| 00015775510 | TP-0820B PAPIER IMPRIMANTE FAX207/FAX208/FAX408 - Replaced by 00144376000 | NC |
| 00001348600 | PR-62 ALIMENTATORE 220VAC-24V PR-62 (CHINA) AC220V-24V POWER SUPPLY UNIT | NC |
| 00001170200 | FAX-5 PRE-AMP UNIT CAVO 15M FAX-5 *15M* - | NC |
| 00159577000 | 04S4168 *10M* CABLE ASSEMBLY 04S4168-3 | NC |
| 00550223000 | ARD-1 MATCHING BOX FS1575/2575 MATCHING BOX PER SSB MF/HF | NC |
| 00159581000 | 04S4168 *50M* CABLE ASSEMBLY 04S4168-3 | NC |
| 00159580000 | 04S4168 *40M* CABLE ASSEMBLY 04S4168-3 | NC |
| 00159579000 | 30-Meter Antenna Cable for FAX/Navtex, 04S4168 | NC |
| 00159578000 | 04S4168 *20M* CABLE ASSEMBLY 04S4168-3 | NC |
| 00124733000 | FAW-6R2A WHIP ANTENNA W/ACCESSORY | NC |
| 00124732000 | FAW-6R2 WHIP ANTENNA W/ACCESSORY | NC |
| 00109340010 | 04S4168 *50M* CABLE ASSEMBLY 04S4168 - Replaced by 00159581000 | NC |
| 00109339010 | 04S4168 *40M* CABLE ASSEMBLY 04S4168 - Replaced by 00159580000 | NC |
| 00109336010 | 04S4168 *10M* CABLE EQUIPE - Replaced by 00159577000 | NC |
| 00107334010 | 04S4176 R4 54 597 WHIP ANTENNA 04S4176 - Replaced by 00130873000 | NC |
| 00001348400 | PR-62 (CHINA) AC100V ALIMENTATION AC/DC | NC |
| 00001170300 | FAX-5 *1M* PREAMPLIFICATEUR | NC |
| 00007519800 | FAX-408-E RECEPTEUR FACSIMILE | NC |
| 00015966211 | CR-2032L/BK LI-METAL BATTERY 0.07G | NC |
