Description
Revolutionary 2 antenna and rate sensor system
In order to calculate roll & pitch data, a satellite compass requires two vectors. The SC30 employs a 2-antenna system that calculates a single vector while a 3-axis rate gyro and acceleration sensors add the 2nd vector. This configuration enables the SC30 to calculate highly accurate roll and pitch data without using a third sensor. The SC30 employs the LAMBDA algorithm developed by Prof. Teussen, Delft University of Technology, The Netherlands.
Product advantages
The SC30 Satellite Compass provides highly accurate attitude information for navigation equipment such as radar, plotter, autopilot, fish finder and sonar. With its compact GPS antenna and built-in processor, it can be used for a wide variety of applications on any type of vessel. This all-in-one system delivers incredibly accurate heading and roll & pitch information as well as heaving information, GPS position, SOG (Speed Over Ground), COG (Course Over Ground) and ROT (Rate Of Turn) data.
Employing a two-antenna system with a 3-axis gyro and acceleration sensors, the SC30 enables high-speed response capability. Advanced digital signal processing techniques compute accurate heading based on sensor data. NMEA2000 interface is standard for simple installation, while the optional interface unit IF-NMEASC is available for conventional NMEA0183, AD10 and contact closure.
Features
The SC30 is compact dome Satellite Compass, NMEA2000 (1.0 degree Heading Accuracy) w/6M cable :
- Display Size: Black Box
- Display Type: Black Box
- Power Usage: 12 VDC or 24 VDC
- Receiver Type: GPS
In the box
1 X GPS antenna
1 X BUSCAN / NMEA2000 cable, 6 m
1 X Installation kit
1 X User Manual
Technical characteristics
Brand : FURUNO
Integrated GPS : 2 antennas
NMEA0183 INPUT : En option
NMEA2000 : 1
NMEA2000 INPUT : OUI
Power input : 12/24 V
Type : Satellite Compass
Parts and accessories
| 00001146900 | IF-NMEASC INTERFACCIA NMEA 0183/2000 SC-30_33_70_130 | 1 398,85 € With VAT (22%) |
| 00150681000 | OP20-50 KIT RETROFIT SC30/SC33 CABLE CONVERSION KIT | 301,83 € With VAT (22%) |
| 00001198000 | SC-30-E-6 COMPAS SATELLITAIRE | NC |
